| Printing |
Print Method |
Direct Thermal Line Printing |
| Resolution |
Standard 203dpi (8dots/mm), |
| Emulated 180dpl{7dots/mm) |
| Print Speed |
Mox.260mm/s |
| Printing Width |
72mm |
| Interface |
Standard |
USB+Seriol+Ethemet |
| Optional |
Blue tooth or Wi-Fi |
| Page Mode |
|
Support |
| Memory |
RAM |
32Mb |
| Flash |
64Mb |
| Fonts |
Chinese |
GBK 24x24dots |
| Alphanumerics |
ASCII 9×17, 12x24dols |
| User-defined |
YES |
| Codepage |
48 |
| Barcode |
1D |
UPC-A. UPC-E, EAN8, EAN13, CODE39, ITF, CODEBAR. CODE128, CODE93 |
| 2D |
PDF417, QR code |
| Graphics |
|
Support bitmap printing with different density and user defined bitmap prinmg. (Max size of each bitmap is 64K. the total size of bitmap is 256k) |
| Detection |
Sensors |
Paper out and paper near end sensors, cover open switch |
| LED Indicator |
Power |
Blue LED |
| Paper |
Orange LED |
| Error |
Red LED |
| Reliability |
TPH Life |
150km |
| Outer Life |
2 million cuts |
| Power Supply |
Input |
AC 100V-240V |
| Output |
DC 24V/2.5A |
| Paper |
PaperType |
Thermal Receipt Paper |
| Paper Width |
58mm/80mm |
| Paper Thickness |
0.056-0.1 mm |
| Roll Paper Diameter |
Max. OD dp83mm |
| Paper Load |
Front or Top paper loading |
| Paper Cut |
Partial cut or full cut |
| Environment |
Operation |
ODegreeC-45Degree C, 25%-85%RH |
| Storage |
-30Degree C-60DegreeC, 5%-95%RH |
| Physical |
Dimensions |
134.8(L)x132{WJxl 32(H)mm |
| Characteristics |
Weight |
1.37KG(Withoul paper roll) |
| Operations and Accessories |
|
USB/Serial Cable, Paper Roll, Power Adopter, Power Cord,CD, Qulct Start Gulde |
| Software |
Emulation |
ESC/POS |
| Driver |
Windows2000/ XP /Win7/Win8 / Win 10/POSReody/Linux /OPOS/ |
| SDK |
WinCE, Win Mobile, Android |
