TVS BS-i302G Table Top Barcode Scanner Original price was: ₹11,995.00.Current price is: ₹8,739.00.
NEWLAND FR27 Desktop Scanner ₹95,000.00
SALE -48%
Category: Brand:

NEWLAND FR-20 Desktop Barcode Scanner

Original price was: ₹20,990.00.Current price is: ₹10,990.00.

  • 640 * 480 CMOS
  • Min. Contrast 30%
  • QUICK TO SWITCH MODE
  • White LED
  • 5 mil @ PCS=90%
Add to Wishlist
Add to Compare
Share it:

  • Diffuse Illumination

FR2080 offers a diffuse and extremely even illumination which closely resembles natural light to make it possible for rapid capture of barcodes on a screen at low brightness levels.

  • Improved Sensitivity

FR2080 is able to speedily “sense” and decode barcodes that are presented to it, markedly increasing throughput and productivity.

  • LED Indicator & Buzzer

FR2080 uses both audible and visible indicators to notify users when it decodes a barcode, ensuring that users can easily keep track of scanner feedback and properly complete scans, saving valuable worker time.

  • Large Scan Window

FR2080 provides a large scan window to further enhance the user experience.

  • Snappy On-screen Barcode Capture

Armed with Newland’s fifth generation of UIMG® technology, FR2080 can decode 1D and 2D barcodes accurately and rapidly and is incredibly reader-friendly on smartphone & tablet displays.

Specifications
Performance
 Image Sensor 640 * 480 CMOS
Illumination White LED
Symbologies PDF417, Data Matrix, QR Code, Micro QR Code, Aztec EAN-8, EAN-13, UPC-A, UPC-E, ISSN, ISBN, Codabar, Standard 2 of 5, Code 128, Code93, ITF-6, ITF-14, GS1 Databar, MSI-Plessey, Code 39, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, Code 11, Plessey, etc.
Resolution >5mil
Scan Angle Pitch: ±50°, Roll: 360°, Skew: ±45°
Min. Symbol Contrast 30%
Scan Window 82mm×64mm
Screen Brightness ≥15%
Field of View Horizontal 69.5°, Vertical 54.8°
Physical
 Dimensions (L×W×H) 100.3(W)×120.3(D)×102.8(H)mm
Weight 296g
Notification Beep, LED indicator
Operating Voltage 5VDC±5%
Current@5VDC 118.4mA (typical), 174.5mA (max.)
Interfaces USB
Rated Power Consumption 837.3mW
Environmental
 Operating Temperature -20°C to 60°C (-4°F to 140°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Humidity 5%~95% (non-condensing)
ESD ±8 KV (air discharge); ±4 KV (direct discharge)
Certifications
 Certificates & Protection FCC Part15 Class B, CE EMC Class B, RoHS
