Newland HR32 Handheld Scanner

Original price was: ₹9,999.00.Current price is: ₹7,348.00.

  • 1D/2D Support
  • 2500 pixels CCD
  • 330Scan/sec Speed
  • 1.5 M Drop test IP-42
  • 3mil @ PCS=90%
Add to Wishlist
Add to Compare
Share it:
Features

  • Durable Construction

The NLS-HR3280, built into an IP42-sealed and drop resistant (1.5m) housing, can stand up to tough environments.

  • Extensive Data Capture Capabilities

Armed with Newland’s six-generation of UIMG® technology, the HR3280 provides the added value of postal barcodes decoding, extending its data capture capabilities.

  • Ideal On-screen Barcode Scanning Solution

The HR3280 delivers unmatched reading performance for various O2O applications involving on-screen barcodes even when the screen is covered with protective film or set to its lowest brightness level.

  • Powerful Data Editing Capability

The scanner allows customizing scanned data with ease and provides supporting software to address diverse application needs.

  • User-friendly Dual-color Illumination

Designed with the end user in mind, the HR3280 combines both red and white LEDs, and the ability to use them separately or together to meet the lighting requirements of various applications.

Specifications
Performance
 Image Sensor 1280×800 (megapixel) CMOS
Illumination Red LED/ White LED
Symbologies EAN-13, EAN-8, UPC-A, UPC-E, ISSN, ISBN, Codabar, Code 128, Code93, ITF-6, ITF-14, Interleaved 2 of 5, Industrial 2 of 5, Standard 2 of 5, Matrix 2 of 5, GS1 Databar, Code 39, Code 11, MSI-Plessey, Plessey, etc. PDF417, QR Code, Data Matrix, Aztec, Maxicode, etc. USPS Postnet, Royal Mail, KIX Post, Australian Postal, etc.
Resolution ≥3mil
Typical Depth of Field 55mm-570mm (13mil) 115mm-170mm (5mil) 85mm-225mm (6.7mil) 65mm-305mm (10mil) 25mm-395mm (15mil)
Scan Angle Pitch: ±55°, Skew: ±55°, Roll: 360°
Min. Symbol Contrast 25%
Field of View Horizontal 39°, Vertical 24°
Aiming Green LED
Physical
 Dimensions (L×W×H) 113.5(W)×73.3(D)×159.0(H)mm
Weight 162g
Notification Beep, LED
Operating Voltage 5VDC±5%
Current@5VDC 238.2mA (typical), 260.5mA (max.) 71.3mA
Interfaces RS-232, USB
Rated Power Consumption 1289.6mW (typical)
Environmental
 Operating Temperature -20°C to 60°C (-4°F to 140°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Humidity 5%~95% (non-condensing)
ESD ±15 KV (air discharge); ±8 KV (contact discharge)
Drop 1.5m
Sealing IP42
Certifications
 Certificates & Protection FCC Part15 Class B, CE EMC Class B, RoHS
