| Resolution |
203 dpi (8 dots/mm) |
| Printing Method |
Thermal Transfer & Direct Thermal |
| Print Speed |
Up to 152.4 mm (6 inches) per second |
| Print Width |
Maximum 108 mm (4.25 inches) |
| Print Length |
Maximum 2,794 mm (110 inches) |
| Physical Dimensions |
204 mm (W) x 164 mm (H) x 280 mm (D) |
| Weight |
2.4 kg (5.29 lbs) |
| Label Roll Capacity |
127 mm (5 inches) outer diameter (OD) |
| Ribbon |
300 m long, maximum OD 67 mm, 1” core ink coated outside |
| Ribbon Width |
40 mm to 110 mm (1.6 inches to 4.3 inches) |
| Processor |
32-bit RISC CPU |
| Memory |
128 MB Flash memory, 64 MB SDRAM |
| Interface |
USB, Serial, and Ethernet |
| Power |
Input: AC 100-240V, 2.5A, 50-60Hz; Output: DC 24V, 2.5A, 60W |
| Sensors |
Transmissive gap sensor, Black mark reflective sensor position adjustable |
| Barcode Support |
- 1D barcodes:
- Code 128UCC, Code 128 subsets A, B, C, EAN128, Interleaved 2 of 5, Interleaved 2 of 5 with check digit, Code 39, Code 39 with check digit, Code 93, EAN13, EAN8, UPCA, UPCE, EAN and UPC 2 5 digits addon, Codabar, Postnet, MSI, MSI with check digit, PLESSEY, China post, ITF14, Code 11, TELEPEN, TELEPENN, PLANET, Code49, Deutsche Post Identcode, Deutsche Post Leitcode, LOGMARS
- 2D barcodes:
- GS1 DataBar, GS1 DataMatrix, Maxicode, AZTEC, PDF417, QR Code, Micro PDF 417
|
| Printer Language |
TSPLEZD Compatible to EPL, ZPL, ZPL II, DPL |
| Media Type |
Continuous, die-cut, black mark, fanfold, notched outside wound |
| Media Width |
20 mm to 112 mm (0.8 inches to 4.4 inches) |
| Media Thickness |
0.06 mm to 0.19 mm (2.36 mil to 7.48 mil) |
| Media Core Diameter |
25.4 mm to 38 mm (1 inch to 1.5 inches) |
| Label Length |
5 mm to 25,400 mm (0.2 inches to 1,000 inches) |
| Environment Conditions |
Operation: 5°C to 40°C, 25% to 85% non-condensing; Storage: -40°C to 60°C, 10% to 90% non-condensing |
